IWATA GRAVITY SPRAYGUN AZ4 JUNIOR HTE
Description
The Air Gunsa range has been specially enhanced by the launch of the AZ4 Junior. This version of the new gun has been specially designed to achieve those small to medium repairs on vehicle body or in general industry applications that can be perfectly repaired with high transfer efficiency, more control and maximum comfort for the operator. Ideal for both water based and solvent based paints.
| Part No. | Fluid Nozzle Size [mm] | Air Pressure@ Gun Inlet [bar] | Air Consumption [l/min] | Fluid Output [ml/min] | Fan Pattern [mm] | Cap # | Pot type / size | Capacity [ml] |
|---|---|---|---|---|---|---|---|---|
| AZ4HTE081C | 0.8 | 1 | 50 | 105 | 120 | AZ4-1 | PCG.2P2 | 200 |
| AZ4HTE101C | 1.0 | 1 | 65 | 105 | 150 | AZ4-1 | PCG.2P2 | 200 |
| AZ4HTE121C | 1.2 | 1 | 80 | 105 | 160 | AZ4-1 | PCG.2P2 | 200 |
| AZ4HTE132C | 1.3 | 2 | 125 | 180 | 180 | AZ4-2 | PCG.2P2 | 200 |
| AZ4HTE152C | 1.5 | 2.5 | 195 | 240 | 180 | AZ4-2 | PCG.2P2 | 200 |
| AZ4HTE182C | 1.8 | 2.5 | 275 | 245 | 185 | AZ4-2 | PCG.2P2 | 200 |
